| Sensor Type |
CMOS, Rolling Shutter
|
CMOS, Rolling Shutter |
CMOS, Rolling Shutter |
CMOS, Global Shutter |
CMOS, Quad Port Progressive Scan |
| Sensor Size |
5.7 mm x 4.28 mm equivalent 1/2.5" diagonal 7.1 mm |
5.70 mm x 4.28 mm equivalent 1/2.4" diagonal 7.13 mm |
7.1 mm x 4.0 mm equivalent 1/2.1" diagonal 8.1 mm |
8.5 mm x 7.1 mm equivalent 2/3" diagonal 11.1 mm |
12.2 mm x 9.8 mm equivalent 1" diagonal 16 mm |
| Pixel Count |
5.0 megapixel: 2560 (H) x 1920 (V) |
5.0 megapixel: 2592 (H) x 1944 (V) |
8.3 megapixel: 3840 (H) x 2160(V) |
5.07 megapixel: 2464 (H) x 2056 (V) |
6 megapixel: 2752 (H) x 2208 (V) |
| Subsampling |
- |
- |
- |
1x1, 2x2 |
- |
| Pixel Size |
2.2 μm x 2.2 μm |
2.2 μm x 2.2 μm |
1.85 μm x 1.85 μm |
3.45 μm x 3.45 μm |
4.54 μm x 4.54 μm |
| Full Well Capacity |
- |
- |
- |
10,500 e- |
15,000 e- |
| Sensor Filter Mask |
RGB Bayer Filter |
RGB Bayer Filter |
RGB Bayer Filter |
RGB Bayer Filter |
RGB Bayer Filter |
| Spectral Sensitivity |
Approx. 400 nm-700 nm, IR filter |
Approx. 400 nm-670 nm, IR filter |
Approx. 400 nm-700 nm, IR filter |
Approx. 380 nm-720 nm, IR cut filter |
Approx. 400 nm-720 nm, IR cut filter |
| Binning |
Digital binning |
No |
No |
Digital binning 1x, 2x, 3x, 4x, 5x |
Digital binning 1x1, 2x2, 3x3, 4x4, 5x5 |
| ROI (Region of Interest) |
Yes (adjustable) |
Yes (adjustable) |
Fixed frame 1080p mode |
Yes (adjustable) |
Yes (adjustable) |
| Readout Noise |
- |
- |
- |
Typ. 2.2 e- @ gain 1x |
Typ. <6.5e- (39 Mhz), Typ. 6 e- (13 MHz) |
| Dark Current |
- |
- |
- |
Typ. < 1.0 e-/p/s @ 25°C |
Typ. <6.5 e- (39 Mhz), Typ. 6 e- (13 Mhz) |
| Dynamic Range |
- |
- |
- |
Typ. 1:4800 |
Typ. 1:2500 |
| Digitization Bit Depth |
8 bit |
8 bit |
8 bit |
12 bit/8 bit |
3x14 bit/ 12 bit/ 8 bit |
| Exposure Time Range |
10 μs - 2 s |
30 μs - 1 s |
61 μs - 1 s |
100 μs - 4 s |
250 μs - 60 s |
| Analog Gain |
No |
Yes |
1x - 22x adjustable |
1x, 2x, 4x, 8x, 16x |
1x, 2x, 3x |
| Frame Rate Live Image/Time Lapse Recording |
Live 20 fps at 800x600, Not recommended for time lapse imaging |
Live 17 fps at 5 MP |
Live Ethernet: 30 fps at 4K/1080p (H.264) USB 3.0: 30 fps at 4K/1080p (MJPEG) HDMI: 30 fps at 4K/1080p Not recommended for timelapse imaging in ZEN |
Live 30 fps at 5 MP 67 fps at 1920 x 1080 (ROI in HD format) 136 fps at 512 x 512 (ROI) |
Live at 19 fps at 6 MP 19 fps at 2752 x 2208; 32 (ROI in HD format) 33 fps at 917 x 733; 51 fps at 550 x 440 |
| Sensor Cooling |
No |
No |
No |
stabalized at 25°C |
Stabalized at 18°C |
| External Trigger |
No |
No |
No |
No |
Yes
|
| Interface |
1x SD card slot, 1x mini USB 2.0, 1x RJ 45 (LAN), 1x HDMI (DVI-D) |
USB 3.0 Micro-B (Camera) to USB 3.0 Standard A (PC/Board) |
USB 3.0 Type C, Ehternet, HDMI, power |
USB 3.0 SuperSpeed (5 Gbit/s); Bandwidth max. 240 MB/s; USB 2.0 optional, with lower speed; |
USB 3.0 SuperSpeed (5 Gbit/s); Bandwidth max. 240 MB/s; USB 2.0 optional, with lower speed; |
| Power Consumption and Supply |
5 W through 2x USB 2.0 |
max. 0.5-1 W through USB 3.0 |
9 W, external power supply |
4W, powered by USB 3.0-Bus from PC |
7W, powered by USB 2.0 and USB 3.0-Bus from PC; |
| Software |
ZEN blue, ZEN core, Labscope |
ZEN blue, ZEN core |
ZEN blue, ZEN core, Labscope |
ZEN blue, ZEN core, Labscope |
ZEN blue, Zen Core |
